Nonwoven sheet cutting machine

  • PPD-NSCM1000

  • Nonwoven sheet cutting machine is our special design model to produce the nonwoven sheet.This model is also suitable for horizontal cutting of roll materials such as non-faulty cloth, dust-free cloth, gold and silver cardboard, plain rainbow paper, white paper, plastic sheet, woven bag, etc.This model also can produce the paper sheet,film sheet as buyer requirement.
    Machine is with PLC touch screen and easy to use.

Features:

1.The electrical main control system adopts computer stepping control or (servo system control), man-machine interface operation,dynamic display;

2.fixed-length control is controlled by an imported stepping motor system, and the automatic identification photoelectric switch is imported from Germany to ensure cutting accuracy.

3.The control method of the whole machine is advanced. The speed of the main machine, imported stepping motor, and feeding motor is controlled by the computer to achieve synchronous operation.It has the advantages of high cutting precision, fast speed, convenient feeding, and neat stacking.

4.Compact structure, high degree of automation, with computer control, variable frequency speed regulation, automatic counting, sound and light alarm, photoelectric tracking and other functions.


Machine data:

Machine name:Nonwoven sheet cutting machine

Maximum cutting width:950mm

Maximum cutting length:1200mm

Maximum unwinding diameter:¢600mm

Maximum cutting speed:50m/min

Cutting accuracy:±0.2mm

Total power:4KW

Machine weight:1000KG

Dimensions:3500×1600×1300mm






Since 1987, Jiaxing Patsons Machinery Co Ltd is focused on different packaging machinery, and packaging material converting machinery etc. Through continuous efforts, we have been the professional in the research & production of stretch film machine, cling film machine, aluminium foil machine, alcohol pad machine, wet wipes machine, paper roll slitter rewinder, paper processing machinery, printing machinery and all kinds of customized packaging material converting machinery.

Patsons china factory Patsons china factory
Patsons china factory certificate
Patsons china factory certificate

FAQ

We have many models of machine, please contact our sales office who will assist you to select the best machine to suit your requirements.
Yes. We have a professional RD team with rich experience to design and manufacturing.
Machine with one year warranty, if any parts broken, we will send new spare parts to buyer via DHL within 24 hours, life-long maintenance.
3 weeks for standard model machine, 30 working days for customized model.
Free fumigation export plywood cases
By sea, by air, by train or others
Due to the Cover-19, we provide online video call for installation guide!
