Aluminium Foil Machine

Fearures:

1:It possess feature like momory control,complete automatic,smooth running,easy to operate.

2:It has passed CE certificate.

3:Aluminum Foil Feeding Machine

Feeding machine design reasonable and stable,good performance for small thickness ad big width material,without wrinkle happen under higher speed running

4:H-type press

Steel Plate Wielded Machine body marked with high rigidity and less deformation.

Crankshaft is arranged in longitudinal direction, which has well-designed structure and beautiful appearance.

The sliding block adopts hexagonal extended guide rails with high precision, and double pneumatic balance sliding block of high precision is used.

It adopts combined pneumatic friction clutch and barking device to ensure steady clutching, low noise level, and flexible action.

It has steel press-down type safety device with simple structure and safe performance.

The imported PLC electronic control system and Duplex safety valve are used to achieve emergent stop, inching, sing action and continuous operation. Electric adjustment of mould load height is adopted, enabling easy operation.

5.Auto stacker

Auto stacker is necessary key part to achieve for complete automatic aluminium foil container production line.

We have lane number from 1 to 5 lanes for different mould production.

Special size can be customized as buyer requirement.

6.Scrap Collecting Device

It is using for collecting the scrap in the production time, avoid that products are not able to be blown out in case some scrap are left in the Mould. It can significantly reduce the labor intensity, Improve working efficiency, and make sure the cleaning of workshop and efficient production

Machine data:

1.Raw material: Aluminum foil; Thickness: 0.030mm ~0.250mm

        Alloy: 8011,8006,3003,3005; Temper O to H24;

2.Max width of Aluminum foil:800mm

3.Max outer diameter of Aluminum foil:700mm

4.Inner core diameter of Aluminum foil:76mm/152mm

5.Running speed:40-68 times/min

6.Cavity:One cavity or multi-cavities

7.Air supply: 0.5- 0.8 Mpa,0.3m3/min

8.Machine dimension: 6000*2600*3300mm

NOTE:Mould size is customized as buyer requirement
