Four side sealing stick mix fruit tugging candy packing machine

  • PPD-SFCP80

  • Four side sealing stick mix fruit tugging candy packing machine is a new type of four-side sealing packaging machine that has been optimized and redesigned based on the experience of long-term research and development of four-side sealing packaging equipment and combined with the experience suggestions put forward by some users.
    The machine control system is newly designed and fully functional. It takes servo control technology as the core, combined with advanced microprocessors, and fully adopts servo technology: it has the advantages of precise film feeding, stable material transfer, and precise bag cutting.
    It is suitable for packaging s Candies, seaweed rolls, spicy strips etc..

Video

Full process:

manual feeding is adopted to the conveyor belt → product into the bag → four-side sealing bag → sealing → cutting → transporting the packaged product (automatic counting)


Features:

1. Adopt advanced servo control system and intelligent control of the whole machine.

2. Newly designed heat-sealing system, tightly sealed; packaging materials of different thicknesses and materials are more adaptable.

3. The temperature of the sealing surface is more uniform and stable.

4. Bag-making mechanism is stable.

5. With 4-axis servo technology, convenient operation!


Machine data:

Machine name: Four side sealing stick mix fruit tugging candy packing machine

Machine model:PPD-SFCP80

Packaging film: paper aluminum, paper plastic, aluminum plastic, aluminized film and other packaging materials, Φ≤350mm, width ≤552mmPackaging film ID: 76mm

Product size:L 400mm,W 50mm(as buyer requirement)

Production speed:80pcs/min

Power: motor 2.2KW heating 3.3KW

Voltage:220v 50Hz

NOTE: ANY SPECIFICATIONS CAN BE CUSTOMIZED.

Four side sealing02.jpg



Since 1987, Jiaxing Patsons Machinery Co Ltd is focused on different packaging machinery, and packaging material converting machinery etc. Through continuous efforts, we have been the professional in the research & production of stretch film machine, cling film machine, aluminium foil machine, alcohol pad machine, wet wipes machine, paper roll slitter rewinder, paper processing machinery, printing machinery and all kinds of customized packaging material converting machinery.

Patsons china factory Patsons china factory
Patsons china factory certificate
Patsons china factory certificate

FAQ

We have many models of machine, please contact our sales office who will assist you to select the best machine to suit your requirements.
Yes. We have a professional RD team with rich experience to design and manufacturing.
Machine with one year warranty, if any parts broken, we will send new spare parts to buyer via DHL within 24 hours, life-long maintenance.
3 weeks for standard model machine, 30 working days for customized model.
Free fumigation export plywood cases
By sea, by air, by train or others
Due to the Cover-19, we provide online video call for installation guide!
